2-Kanal Logger

Der MSFM 2-Kanal-Datenlogger ist ein präzises 2-Kanal-Logging-System, das z.B. Ihren Leitungswasserverbrauch genau überwacht. Es bietet eine Fernüberwachung nach Industriestandard und verfügt über eine speziell entwickelte Antenne, um das Signal an unterirdischen Standorten zu maximieren.

  • Suitable for any pulse output enabled water meter.
  • Data can be used for leakage, billing or consumption purposes.
  • 4 individual alarms provide issue notification and data updates when you need them.
Angebot einholen

Funktionsweise

The MSFM GRPS 2 channel datalogger is a precision GPRS 2-channel system that accurately monitors your incoming clean/mains water consumption.

It provides industry standard remote monitoring and has a specially designed aerial to maximise the signal in underground locations.

  • Suitable for any pulse output enabled water meter.
  • Data can be used for leakage, billing or consumption purposes.
  • 4 individual alarms provide issue notification and data updates when you need them.

Technische Daten

Digital Inputs

Up to 2: pulses counted over, and recorded at, preset intervals

Tamper/status and event recording supported

Connects to all meters that provide pulse or 4-20 mA output

Optional Integrated Pressure Measurement

Input range: 0 – 100m (0 – 10 bar) or 0 – 200m (0 – 20 bar)

+/-0.5% accuracy

+/-0.5% resolution (optional +/-0.1%)

GSM Modem

Quad band: 900MHz, 1800MHz / 850MHz, 1900MHz

Integral antenna

Optional external antenna

Serial Port

Type: full duplex, asynchronous

Data rate: 1200, 2400, 4800, 9600 bps

Memory

Size: 128K, allocatable between channels as required (maximum 64K per channel)

Type: solid state, non-volatile

Clock Type:

Crystal controlled calendar clock with leap year adjustment

Accuracy: 100 seconds per monthly maximum error over operating temperature range

Synchronisation: option to synchronise clock to GSM network

Supply

Internal lithium battery pack

Optional high capacity external lithium battery pack, user replaceable

Life: typical battery life >5 years (depending on mode of use)

Data Transmission

SMS or GPRS. 15 minutes, 30 minutes, 1 hour, 1 day, 1 week or monthly at programmable date and time

Recording

Recording interval: programmable between 1 second and 1 hour

Data storage: rotating store or store until full

Supports average and statistical recording (minimum, maximum, mean, standard deviation) over a defined logging interval

Alarm Dial-Out

High/low threshold and profile alarms independently configurable on each channel

Option to update data on alarm and more frequently thereafter

Eigenschaften

Operating ambient temperature: -20°C to +50°C

Schutzklasse: IP68

(submersion at 1m depth for >24 hours)

Mechanical

Diameter: 149mm

Height: 146.5mm

Weight: 0.750kg
